2025 – Tracking Devices
At the registration boot, first day of your training, you will get your tracking device that you need to mount (with our assistance) to your vehicle.
Your tracking device MUST be functional all the time, during the training. Please do your berst to prepare your vehicle (wiring) as per instructions below! If you there is any reason why you can’t do it yourself, don’t worry, we will halp you on the spot – installation of the devices is a part of the program anyway ;).
Live tracking application
Public live tracking application will be availible during the training. Link for a live tracking will be send after all the riders will be registered for the rally.
Instalation
Riders have to prepare the wires and connectors / terminals to connect the trackers to the Battery.
Devices is light and small. To attach the device Zip Ties are everything you need.
Needed:
- 1 m (or longer) of electric wire (Ground and Power)
- 6.3 x 0.8. insulated FEMALE connectors / terminals
- 5A fuse, installed on Power wire
- Zip Ties (good quality)
Please prepare everything as per scheme below:
Make sure to have some Zip Ties with you and have some extra in case you need to repair those after few days of riding or after droping bike down or else.
Tracking device (GSM / GPRS / GNSS) features:
- Quad band module (GSM 850 / 900 / 1800 / 1900 MHz);
- GPRS Multi-Slot class 12 (Up to 85,6 kbps);
- Integrated GNSS receiver;
- Up to -165 dBm GNSS receiver sensitivity.
Hardware features:
- 128 MB internal Flash memory (422 400 Records);
- Integrated Li-ion battery 3.75V, 1800mAh;
- Internal High Gain GSM antenna;
- Internal High Gain GNSS antenna;
- Operating temperature -20. +50 °C
- Voltage +6 V … +30 V
- IP67 waterproof rating
- Dimensions 72,5 x 73 x 27,3 mm (L x W x H)
- Certification & approvals CE/RED, Pulse 5a, E-Mark, EAC, RoHS, REACH, SIRIM QAS
